5. cutter installation method 4 (end mill) – IBM EGX-400 User Manual

Page 55

Text mode
Original mode

Chapter 3 - Preparations

Lock nut

Lock nut : Tighten
[AUTO Z CONTROL] : OFF
[REVOLUTION] : ON

Collet for end mills (optional)

End mill

3-5. Cutter Installation Method 4 (End Mill)

This is for when you perform three-dimensional cutting of reliefs and the like using an end mill. An optionally available
collet set for end mills is required to install an end mill.
