41 Chapter 3 - Preparations
3-2. Cutter Installation Method 1 (With Nose Unit)
14 Close the spindle cover.
Cutting Parameters When Using the Nose Unit
When you use the preceding method, there is no need to set the cutting-in depth or the cut-out amount by a software or
the operation panel. The cutting-in depth is determined mechanically by the amount of tightening of the nose unit.
For more information about how to set the cutting parameters
☞ See p.59 "Setting the Cutting Parameters"
☞ See p.134 " Examples of Settings for Cutting Parameters"
For detailed information about the nose unit
☞ See p.110 "Detailed Description of the Menus," the section " AUTO Z CONTROL "
☞ See p.103 "Detailed Description of the Nose Unit"
