Page 124
120
Chapter 7 - Maintenance
X 0 Y 0
Z 0 8000RPM
7-2. Maintenance and Inspection
Spindle Maintenance
The spindle unit and the belt are consumable components. As a general guide, it should be replaced after every 2,000
hours. As a general guide, the spindle motor should be replaced after every 6,000 hours.
When performing replacement, read the documentation included with the replacement unit or contact your authorized
Roland DG Corp. dealer or Roland DG Corp. service center.
This machine has a feature that lets you view the total working time of the spindle. Refer to this to determine when
replacement is needed.
I/O
O
THERS
TEACHING SELF
REVOLUTION
REVOLUTION TIME
26 Hours
