SPECIFICATIONS
83
SPECIFICATIONS
Recording: Rotary two head Helical Scan Azimuth Recording
Video: NTSC Color EIA Standard
Cassette: VHS Type
Heads: 4 video heads 2 for SP, 2 for EP, 1 Flying erase head
2 Hi-Fi audio heads
1 Full track audio/video erase head
1 Combination head for control track, audio erase
and record/play (3 heads/single housing)
Tape Speed: 33.35mm / sec (SP), 16.67mm / sec (LP)(playback only),
11.12mm / sec (EP)
Tape Width: 12.7 mm
RF Output: Channel 3 or Channel 4
RF Input: UHF/VHF 75 ohm
Tuning Range: VHF LOW CH, 2 - 6 (54MHz - 88MHz)
VHF MID CH, A-5 - A-1 and A-I (90MHz - 174MHz) CATV
VHF HIGH CH, 7 - 13 (174MHz - 216MHz)
VHF SUPER CH, J - W (216MHz - 300MHz) CATV
VHF HYPER CH, W+1 - W+28 (300MHz - 468MHz) CATV
UHF CH, 14 - 69, W+29 - W+84 (470MHz - 806MHz)
Video Input: 1-2 Vp-p 75ohm unbalanced
Video Output: 1 Vp-p 75ohm unbalanced
Audio Input 316mV rms (-7.8dB) 50 kohm
Audio Output 316mV rms (-7.8dB) 1.5 kohm
Video Recording S/N: Better than 45dB (SP), better than 40dB (EP)
Horizontal Resolution: 240 lines (SP), 220 lines (LP)(playback only), 230 lines (EP)
Audio Response: 50Hz - 10kHZ (SP), 100Hz - 6kHZ (EP)
Audio S/N: Better than 43dB (SP), better than 40dB (EP)
Hi-Fi Audio:
Frequency Range: 20 Hz to 20 kHz
Dynamic Range: 90 dB
Wow and Flutter: Less than 0.005% WRMS
Power Input: AC120V 60Hz
Power Consumption: 28W nominal
Cabinet Size: 14-15/16" (W) x 3-1/4" (H) x 13-1/8" (D)
38.0cm (W) x 8.2cm (H) x 33.4cm (D)
Weight: 11.7 lbs. (5.3 kg)
Accessories: 1 - Coaxial cable, 1 - Remote control unit, 2 - Batteries
1 remote control unit (Part No. 5616491), 2 AA batteries
Design and specifications subject to change without notice.
