66
Standard Operations
5.12.3 Profibus/Modbus configuration example
Table 17 and Table 18 show a Profibus/Modbus configuration example.
For more information concerning Profibus configuration settings, refer to section 6.3.4.1
on page 109 .
For more information concerning Modbus configuration settings, refer to section 6.3.4.2
on page 111 .
Table 17 Profibus configuration example
Profibus
address
Slave Byte Device Data name
5 Configured Slave
1,2
AMTAX SC
ERROR
3,4 STATUS
5,6,7,8 CUVETTE TEMP
9,10,11,12 MEASURED VALUE 1
13,14
mA INPUT INT
ERROR
15,16, STATUS
17,18,19,20 INPUT CURRENT 1
21,22 DIGITAL INPUT 2
23,24,25,26 OUTPUT VALUE 3
27,28 DIGITAL INPUIT 4
Table 18 Modbus configuration example with virtual slaves
Modbus
address
Slave Register Device Data name
5 Configured Slave
40001
AMTAX SC
ERROR
40002 STATUS
40003 CUVETTE TEMP
40005 MEASURED VALUE 1
40007
mA INPUT INT
ERROR
40008 STATUS
40009 INPUT CURRENT 1
40011 DIGITAL INPUT 2
40012 OUTPUT VALUE 3
40014 DIGITAL INPUIT 4
6
First virtual slave
(AMTAX SC)
40001
AMTAX SC (complete)
See AMTAX SC profile
40002 See AMTAX SC profile
... See AMTAX SC profile
7
Second virtual slave
(mA INPUT INT)
40001
mA INPUT INT (complete)
See mA INPUT INT profile
40002 See mA INPUT INT profile
... See mA INPUT INT profile
