Advanced Operations
Figure 64
shows the behavior of the relay in the Timer mode.
Figure 64 Timer mode—Relay behavior
1
OFF Duration
3
OFF Delay
2
Duration
4
Time (x-axis)
Table 36 Color/line code for
Figure 64
Relay contact (DUTY CYCLE=DIRECT)
Relay contact (DUTY CYCLE=REVERSE)
