14
Installation
3.2.2 Vertical or horizontal pipe mounting
for mounting descriptions. For more information on pipe mounting refer
to the instructions supplied with the mounting kit.
3.2.3 Panel Mounting
Refer to the instruction sheet supplied with the mounting hardware for installation
instructions.
3.2.4 Sun-shield
The optional sun-shield is highly recommended for all outdoor installations. Refer to the
instruction sheet supplied with the sun-shield for installation instructions.
3.3
Wiring safety information
DANGER
Electrocution hazard. Always disconnect power to the instrument when making
electrical connections.
When making any wiring connections to the sc1000 Controller, the following warnings
and notes must be adhered to, as well as any warnings and notes found throughout the
individual installation sections. For more safety information refer to
Remove the display module before performing any wiring tasks (
).
Figure 4 Pipe mounting hardware
1
Bracket, pipe mount (LZY001)
3
Flat washer (4x) (LZX948)
2
Rubber pads (8x) (LZX948)
4
Hexagon head screw (4x) M5 x 30 mm (LZX948)
