Advanced Operations
Figure 62
shows the behavior of the relay in the PWM Control/linear mode.
Figure 62 Relay behavior—PWM Control/Linear mode
1
High alarm
4
Time (x-axis)
2
Low alarm
5
Selected source (y-axis)
3
Period
Table 34 Color/line code for
Figure 62
Selected source
Relay contact
