ACT
LINE ERR
(*1)
T/R
LOOP
(*1)
Line state Detail of state State as seen by SXMP
Line state
indication in
MMI and
browser
-- (*3) Being initialized. Being initialized (3). initialize
G (*3) Being operated In normal
operation. In standby (3). active up
-- (*3) Line fault being
occurred. In operation (line fault being
occurred (8). active down
G (*3) Line test. Line being tested (9). test
-- -- In fault. In fault (4). fault
-- -- Command being
blocked. In maintenance (10). closed
-- -- Not used. Configuration
definition not set
yet Not used.
Configuration definition not
set yet. (10) unused
-- -- Configuration definitions
not agreed. Configuration definitions not
agreed. (11) mismatch
(*1): G: Lights in green, Y: Lights in yellow, -: Goes off
(*2): Meaning and value of SMNP private MIB and gr2kPhysLineOperStatus
(*3): The T/R LED lights and goes off by H/W. In lighting conditions, this LED lights in green when the logical value of
