Rear panel components – HP DL980 G7 User Manual
Page 10
Server component identification 10
LED
Component
LOWER CPU
Indicates lower CPU tray with associated CPUs,
memory risers and DIMMs
MEMORY BOARD X DIMM
1A-8D
DIMM slot
Processor and memory board configuration / logical (physical)
location
Upper processor memory board is shown on the left. Lower processor memory board is shown on the right.
Rear panel components
