HP 8517B S-Parameter Test Set Manual 5-1
5
Troubleshooting the Test Set
The troubleshooting strategy for the HP 8517B S-Parameter test set is a
systematic sequence of procedures. The information may be used after
system-level troubleshooting has identified the test set as the problem
instrument.
Use the troubleshooting flowchart in Figure 5-2 to help isolate the faulty
assembly. Notice procedure numbers within some of the flow diagram
blocks. These are keyed to troubleshooting procedures. Perform the
numbered procedure associated with each block as you progress through the
chart.
Refer to the block diagrams, located at the end of this section, to help you
understand the test set’s operation.
