1-10 HP 8517B S-Parameter Test Set Manual
Getting Started
Accessories
Accessories
The accessories supplied with the test set, including part numbers, are listed
in “Accessories Supplied” in this section and in the “Replaceable Parts List”
of this manual.
Accessories Available Table 1-5 describes accessories available for the HP 8517B test set. For
additional HP 8510C system accessories information, refer to the HP 8510C
manual set.
Table 1-5 HP 8517B Test Set Accessories Available
Accessory Type Accessory Model Number Contents or Description
Calibration Kit 1 HP 85056A 2.4 mm Calibration Kit Contains open and short circuits
Fixed and sliding loads (2)
2.4 mm to 2.4 mm adapters
2.4 mm connector tools and gauges
Verification Kit 1 HP 85057S 2.4 mm Verification Kit Contains precision airline, mismatched airline,
20 dB and 40 dB attenuators
Cables HP 85133C 2.4 mm Test Port Return
Cable Used when measuring a 2.4 mm-ported device connected directly to
Port 1 of the test set. The test port return cable is connected
between the device under test and Port 2.
HP 85133D 2.4 mm Test Port Return
Cable Set Used when measuring a 2.4 mm-ported device connected between
the cable ends.
HP 85133E 2.4 mm Flexible Test Port
Return Cable Used when measuring a 2.4 mm-ported device connected directly to
Port 1 of the test set. The test port return cable is connected
between the device under test and Port 2.
HP 85133F 2.4 mm Flexible Test Port
Return Cable Set Used when measuring a 2.4 mm-ported device connected between
the cable ends.
HP 85134D 3.5 mm Test Port Return
Cable Set Used when measuring a 3.5 mm device under test connected
between the cable ends.
HP 85134E 3.5 mm Flexible Test Port
Return Cable Used when measuring one end of a 3.5 mm device connected
directly to an HP 85130F adapter at Port 1. The test-port return
cable is connected between the device and Port 2.
HP 85134F 3.5 mm Flexible Test Port
Return Cable Set Used when measuring a 3.5 mm device connected between the
cable ends.
HP 85135C 7 mm Test Port Return
Cable Used when measuring one end of a 7 mm device connected
directly to an HP 85130E adapter at Port 1. The test port return
cable is connected between the device and Port 2.
Cables (Continued) HP 85135D 7 mm Test Port Return
Cable Set Used when measuring a 7 mm device connected between the cable
ends.
