Commands

104

Fibre Channel Transport ID

Parallel SCSI Transport ID

7

6

5

4

3

2

1

0

0

Format Code (00b)

Reserved (0)

Protocol Identifier (0)

1

Reserved (0)

7
8

(MSB)

World Wide Name

15

(LSB)

16

Reserved (0)

23

7

6

5

4

3

2

1

0

0

Format Code (00b)

Reserved (0)

Protocol Identifier (1h)

1

Reserved (0)

2

(MSB)

SCSI Address

3

(LSB)

4

(MSB)

Relative Port Identifier (0)

7

(LSB)

8

Reserved (0)

23
