22

Part # 25000102

Installation and Operations Manual

Carlyle

Part No.

Danfoss

Part No.

Time

Delay

Pressure

Diff. Psi (bar)

Reset

Cut-In

Cut-Out

634-2008

OR

P529-2130

60B2101

45 sec.

8 – 11

(.55 - .76)

4 - 8

(.28 - .55)

Manual

634-2050

OR

P529-2100

60B2151

Carlyle

Part No.

Johnson

Part No.

Time

Delay

Pressure

Diff. Psi (bar)

Reset

Cut-In

Cut-Out

O6DA660115

P345

45 sec.

8 – 11

(.55 - .76)

4 - 8

(.28 - .55)

Manual

Compressor Model

Multiplication Factor

For 1 Bank Unloaded

Multiplication Factor

For 2 Bank Unloaded

Capacity

Power

EER

Capacity

Power

EER

All 4 Cylinder Models

.49

.57

.86

-

-

-

All 6 Cylinder Models

.67

.73

.92

.32

.46

.70

Application

Suction Pressure

Range Psi (bar)

P Required-Discharge Minus

Suction Pressure Psi (bar)

O6D

O6E

L.T. R-502, 404A, 507

10-25

(1.7-2.7)

30

(2.1)

30

(2.1)

M.T. R-502, 404A, 507

30-60

(3.1-5.2)

40

(2.8)

45

(3.1)

L.T. R-12, 134A

10-30

(1.7-3.1)

30

(2.1)

35

(2.4)

M.T. R-22 or H.T. R-22

30-90

(3.1-7.2)

50

(3.5)

55

(3.8)

3-Phase Voltage Monitor

The microprocessor-based voltage and phase sensing circuit

constantly monitors the three phase voltages to detect harmful

power line conditions. When a harmful condition is detected, the

phase monitor output relay is deactivated after a specified trip

delay. The output relay reactivates after power line conditions

return to an acceptable level for a specified amount of time

(Restart Delay). The trip delay prevents nuisance tripping due

to rapidly fluctuating power line conditions.
The Bicolor LED indicator light is green in normal conditions

and red during trip conditions. On initial start-up, if the light

is continuously red, the unit electrical phase may need to be

reversed. Each main power line should be checked for proper

voltage and imbalance prior to reversing a phase. Also check

the settings of the Voltage Monitor for proper field condition.

For semi-hermetic compressor units, two of the three power

monitor leads on the Voltage Monitor to L1, L2, and L3 may

need to be switched. For units with Scroll

®

or Screw compressors,

which are rotation sensitive, two of the main power lines to the

compressor unit will have to be switched to match the correct

rotation of the compressors. The rotation of Screw and Scroll

®

compressors has been properly phased in the manufacturing

plant prior to shipping.

Table 14. Oil Safety Switch

Table 15. Part Load Performance Multipliers

Multiply compressor rating data by above factors when used with blocked suction unloading

Table 16. Required Differential Pressure for Unloader Operation
