14

Part # 25000102

Installation and Operations Manual

System

Capacity

BTU/H

Suction Line Size

Suction Temperature

40˚F

Equivalent Lengths

20˚F

Equivalent Lengths

10˚F

Equivalent Lengths

0˚F

Equivalent

25’ 50’ 75’ 100’ 150’ 200’ 25’ 50’ 75’ 100’ 150’ 200’ 25’ 50’ 75’ 100’ 150’ 200’ 25’ 50’ 75’

1,000

3/8

3/8

3/8

3/8

3/8

3/8

3/8

3/8

3/8

3/8

3/8

3/8

3/8

3/8

3/8

3/8

3/8

1/2

3/8

3/8

3/8

3,000

3/8

3/8

3/8

1/2

1/2

1/2

3/8

1/2

1/2

1/2

5/8

5/8

3/8

1/2

1/2

1/2

5/8

5/8

1/2

1/2

1/2

4,000

3/8

3/8

1/2

1/2

1/2

1/2

3/8

1/2

1/2

1/2

5/8

5/8

1/2

1/2

1/2

5/8

5/8

5/8

1/2

1/2

5/8

6,000

1/2

1/2

1/2

5/8

5/8

5/8

1/2

1/2

5/8

5/8

5/8

5/8

1/2

5/8

5/8

5/8

7/8

7/8

5/8

5/8

5/8

9,000

1/2

5/8

5/8

5/8

7/8

7/8

1/2

5/8

5/8

5/8

7/8

7/8

5/8

5/8

7/8

7/8

7/8

7/8

5/8

7/8

7/8

12,000

5/8

5/8

5/8

7/8

7/8

7/8

5/8

5/8

7/8

7/8

7/8

7/8

5/8

7/8

7/8

7/8

7/8

7/8

5/8

7/8

7/8

15,000

5/8

5/8

7/8

7/8

7/8

7/8

5/8

7/8

7/8

7/8

7/8

7/8

7/8

7/8

7/8

7/8 1-1/8 1-1/8 7/8

7/8

7/8

18,000

5/8

7/8

7/8

7/8

7/8 1-1/8 5/8

7/8

7/8

7/8

7/8 1-1/8 7/8

7/8

7/8

7/8 1-1/8 1-1/8 7/8

7/8 1-1/8

24,000

5/8

7/8

7/8

7/8 1-1/8 1-1/8 7/8

7/8

7/8

7/8 1-1/8 1-1/8 7/8

7/8 1-1/8 1-1/8 1-1/8 1-1/8 7/8 1-1/8 1-1/8

30,000

7/8

7/8

7/8 1-1/8 1-1/8 1-1/8 7/8

7/8

7/8 1-1/8 1-1/8 1-1/8 7/8 1-1/8 1-1/8 1-1/8 1-1/8 1-3/8 7/8 1-1/8 1-1/8

36,000

7/8 1-1/8 1-1/8 1-1/8 1-1/8 1-3/8 7/8 1-1/8 1-1/8 1-1/8 1-1/8 1-3/8 7/8 1-1/8 1-1/8 1-1/8 1-3/8 1-3/8 1-1/8 1-1/8 1-1/8

42,000

7/8 1-1/8 1-1/8 1-1/8 1-1/8 1-3/8 7/8 1-1/8 1-1/8 1-1/8 1-3/8 1-3/8 1-1/8 1-1/8 1-1/8 1-3/8 1-3/8 1-3/8 1-1/8 1-1/8 1-3/8

48,000

7/8 1-1/8 1-1/8 1-1/8 1-1/8 1-3/8 7/8 1-1/8 1-1/8 1-1/8 1-3/8 1-3/8 1-1/8 1-1/8 1-3/8 1-3/8 1-3/8 1-5/8 1-1/8 1-3/8 1-3/8

54,000

7/8 1-1/8 1-1/8 1-1/8 1-3/8 1-3/8 1-1/8 1-1/8 1-1/8 1-3/8 1-3/8 1-3/8 1-1/8 1-3/8 1-3/8 1-3/8 1-5/8 1-5/8 1-1/8 1-3/8 1-3/8

60,000

7/8 1-1/8 1-1/8 1-1/8 1-3/8 1-3/8 1-1/8 1-1/8 1-1/8 1-3/8 1-3/8 1-5/8 1-1/8 1-3/8 1-3/8 1-3/8 1-5/8 1-5/8 1-1/8 1-3/8 1-3/8

66,000

7/8 1-1/8 1-1/8 1-3/8 1-3/8 1-3/8 1-1/8 1-1/8 1-3/8 1-3/8 1-3/8 1-5/8 1-1/8 1-3/8 1-3/8 1-3/8 1-5/8 1-5/8 1-1/8 1-3/8 1-5/8

72,000

1-1/8 1-1/8 1-1/8 1-3/8 1-3/8 1-3/8 1-1/8 1-3/8 1-3/8 1-3/8 1-5/8 1-5/8 1-1/8 1-3/8 1-3/8 1-5/8 1-5/8 1-5/8 1-3/8 1-3/8 1-5/8

78,000

1-1/8 1-1/8 1-3/8 1-3/8 1-3/8 1-5/8 1-1/8 1-3/8 1-3/8 1-3/8 1-5/8 1-5/8 1-1/8 1-3/8 1-5/8 1-5/8 1-5/8 2-1/8 1-3/8 1-3/8 1-5/8

84,000

1-1/8 1-1/8 1-3/8 1-3/8 1-3/8 1-5/8 1-1/8 1-3/8 1-3/8 1-3/8 1-5/8 1-5/8 1-3/8 1-3/8 1-5/8 1-5/8 1-5/8 2-1/8 1-3/8 1-5/8 1-5/8

90,000

1-1/8 1-3/8 1-3/8 1-3/8 1-5/8 1-5/8 1-1/8 1-3/8 1-3/8 1-5/8 1-5/8 2-1/8 1-3/8 1-3/8 1-5/8 1-5/8 2-1/8 2-1/8 1-3/8 1-5/8 1-5/8

120,000

1-1/8 1-3/8 1-3/8 1-5/8 1-5/8 2-1/8 1-3/8 1-3/8 1-5/8 1-5/8 2-1/8 2-1/8 1-3/8 1-5/8 1-5/8 2-1/8 2-1/8 2-1/8 1-5/8 1-5/8 2-1/8

150,000

1-3/8 1-3/8 1-5/8 1-5/8 2-1/8 2-1/8 1-3/8 1-5/8 1-5/8 2-1/8 2-1/8 2-1/8 2-1/8 1-5/8 1-5/8 2-1/8 2-1/8 2-5/8 1-5/8 2-1/8 2-1/8

180,000

1-3/8 1-5/8 1-5/8 2-1/8 2-1/8 2-1/8 1-3/8 1-5/8 2-1/8 2-1/8 2-1/8 2-1/8 1-5/8 2-1/8 2-1/8 2-1/8 2-5/8 2-5/8 1-5/8 2-1/8 2-1/8

210,000

1-3/8 1-5/8 1-5/8 2-1/8 2-1/8 2-1/8 1-5/8 2-1/8 2-1/8 2-1/8 2-1/8 2-5/8 1-5/8 2-1/8 2-1/8 2-1/8 2-5/8 2-5/8 2-1/8 2-1/8 2-1/8

240,000

1-5/8 1-5/8 2-1/8 2-1/8 2-1/8 2-5/8 1-5/8 2-1/8 2-1/8 2-1/8 2-5/8 2-5/8 2-1/8 2-1/8 2-1/8 2-5/8 2-5/8 2-5/8 2-1/8 2-1/8 2-5/8

300,000

1-5/8 2-1/8 2-1/8 2-1/8 2-5/8 2-5/8 2-1/8 2-1/8 2-1/8 2-5/8 2-5/8 2-5/8 2-1/8 2-1/8 2-5/8 2-5/8 2-5/8 3-1/8 2-1/8 2-5/8 2-5/8

360,000

2-1/8 2-1/8 2-1/8 2-5/8 2-5/8 2-5/8 2-1/8 2-1/8 2-5/8 2-5/8 2-5/8 3-1/8 2-1/8 2-5/8 2-5/8 2-5/8 3-1/8 3-1/8 2-1/8 2-5/8 2-5/8

480,000

2-1/8 2-1/8 2-5/8 2-5/8 2-5/8 3-1/8 2-1/8 2-5/8 2-5/8 2-5/8 3-1/8 3-1/8 2-1/8 2-5/8 2-5/8 3-1/8 3-1/8 3-5/8 2-5/8 2-5/8 3-1/8

600,000

2-1/8 2-5/8 2-5/8 2-5/8 3-1/8 3-1/8 2-1/8 2-5/8 3-1/8 3-1/8 3-1/8 3-5/8 2-5/8 2-5/8 3-1/8 3-1/8 3-5/8 3-5/8 2-5/8 3-1/8 3-1/8

720,000

2-1/8 2-5/8 3-1/8 3-1/8 3-1/8 3-5/8 2-5/8 3-1/8 3-1/8 3-5/8 3-5/8 4-1/8 2-5/8 3-1/8 3-5/8 3-5/8 4-1/8 4-1/8 3-1/8 3-5/8 3-5/8

900,000

2-5/8 3-1/8 3-1/8 3-1/8 3-5/8 3-5/8 3-1/8 3-1/8 3-5/8 3-5/8 4-1/8 4-1/8 3-1/8 3-5/8 3-5/8 4-1/8 4-1/8 4-1/8 3-1/8 3-5/8 4-1/8

* NOTES:
1. Sizes that are highlighted indicate maximum suction line sizes that should be

used for risers. Riser size should not exceed horizontal size. Properly placed

suction traps must also be used for adequate oil return. All sizes shown are for

OD Type L copper tubing

2. Suction line sizes selected at pressure drop equivalent to 2˚F. Reduce estimate

of system capacity accordingly

3. Recommended liquid line size may increase with reverse cycle hot

gas systems

4. If system load drops below 40% of design, consideration to installing double

suction risers should be made

Table 6A. Recommended Line Sizes for R-22*
