Hoshizaki DCM-500BWH-OS - Manual (Page 50)

50
Fig. 1
Extruding Head and
Upper Bearing
Evaporator
Allen Head Cap Screw
with Washer
Allen Head Cap Screw
Housing and
Lower Bearing
Gear Motor
Barrier
Spline Coupling
O-Ring
Mechanical Seal
Auger
Cutter
Auger Pin
Hex Head Bolt
with Washer
D. Removal and Replacement of Evaporator Assembly Components
CAUTION
Make sure the extruding head heater is installed and connected after service.
Extruding Head
Heater
Washer
Spout B
Spout A
Power Switch
Control Switch
Dispense Mode Switch
Evaporator Assembly
Evaporator
Bracket
