5
I. Specifications
A. Icemaker
1. DCM-500BAH
Note: We reserve the right to make changes in specifications and design without prior
notice.
AC SUPPLY VOLTAGE 115/60/1
COMPRESSOR 120 V 7.9 RLA 51 LRA
GEAR MOTOR 120 V 2.4 FLA 1/4 HP
FAN MOTOR 120 V 1.0 FLA 50 W
AGITATING MOTOR 120 V 0.9 FLA 55 W
DISPENSING MOTOR 120 V 0.9 FLA 55 W
OTHERS 120 V 0.2 A
MAXIMUM FUSE SIZE 20 A
MAX. HACR BREAKER (USA ONLY) 20 A
MAX. CIRC. BREAKER (CANADA ONLY) 20 A
MINIMUM CIRCUIT AMPACITY 20 A
APPROXIMATE ICE PRODUCTION Ambient WATER TEMP. (°F)
PER 24 HR. Temp. (°F) 50 70 90
lbs./day ( kg/day ) 70 *535 (243) 510 (231) 485 (220)
Reference without * marks 80 461 (209) 438 (199) 416 (189)
90 396 (179) *385 (175) 358 (162)
100 340 (154) 323 (147) *304 (138)
SHAPE OF ICE Cubelet (Compressed Flake Ice)
ICE QUALITY Apprx. 90% Ice (90/70° F, CONDUCTIVITY 200 µs/cm)
APPROXIMATE STORAGE CAPACITY 40 lbs.
ELECTRIC & WATER CONSUMPTION 90/70°F 70/50°F
ELECTRIC W (kWH/100 lbs.) 1055 (6.6) 985 (4.4)
POTABLE WATER 46 (11.9) 64 (11.9)
gal./24HR (gal./100 lbs.)
EXTERIOR DIMENSIONS (WxDxH) 26" x 22-1/2" x 40" ( 661 x 571 x 1016 mm)
EXTERIOR FINISH Stainless Steel, Galvanized Steel (Rear)
WEIGHT NET 251 lbs. (114 kg), Shipping 276 lbs. (125 kg)
CONNECTIONS - ELECTRIC Permanent Connection
- WATER SUPPLY Inlet 1/2" FPT
- DRAIN Outlet 3/4" FPT x2
ICE MAKING SYSTEM Auger type
HARVESTING SYSTEM Direct Driven Auger ( 1/4 HP Gear Motor )
ICE MAKING WATER CONTROL Float Switch
COOLING WATER CONTROL N/A
BIN CONTROL SYSTEM Mechanical Bin Control ( Proximity Sw. )
COMPRESSOR Hermetic, Model RS43C2E-CAA-219
CONDENSER Air-cooled, Fin and tube type
EVAPORATOR Copper Tube on Cylinder
REFRIGERANT CONTROL Thermostatic Expansion Valve
REFRIGERANT CHARGE R404A 1 lb 4.1 oz. (570g)
DESIGN PRESSURE High 460 PSIG Low 290 PSIG
P.C. BOARD CIRCUIT PROTECTION High Voltage Cut-out Relay
COMPRESSOR PROTECTION Auto-reset Overload Protector
GEAR MOTOR PROTECTION Auto-reset Thermal Protector
Fuse
REFRIGERANT CIRCUIT PROTECTION Auto-reset High Pressure Control Switch
LOW WATER PROTECTION Float Switch and Timer
ACCESSORIES - SUPPLIED Spare Fuse
- REQUIRED Legs
OPERATING CONDITIONS VOLTAGE RANGE 104-127 V
AMBIENT TEMP. 45-100 F
WATER SUPPLY TEMP. 45-90 F
WATER SUPPLY PRESSURE 10-113 PSIG
ENG F-013.0.1196
