Hoshizaki DCM-500BWH-OS User Manual
Page 10
10
2. DCM-500BWH(-OS)
Storage Bin
Inlet Water Valve
Reservoir
Control Box
Water-Cooled
Condenser
Spout Cover
Evaporator Assembly
Compressor
Dispensing Motor
Agitating Motor
Agitator
Ice Dispensing
Auger
Dispensing Water
Valve
Gear Motor
Spout B
Float Switch
Dispense Mode Switch
Control Switch
Shutter Assembly
Power Switch
Drier
Spout A
Drain Water Valve
Door Switch
Expansion Valve
