Dcm-500bwh(-os) – Hoshizaki DCM-500BWH-OS User Manual
Page 22
2. DCM-500BWH(-OS)
Inlet
Water
Valve
Dispensing
Water Valve
Drain
Valve
Float Switch
Water Level
To Drain
Evaporator
Spout
Expansion
Valve
Gear Motor
Overflow
Reservoir
Water Supply
Drier
Water-Cooled
Condenser
High
Pressure
Switch
Access
Valve
Access
Valve
Compressor
Water Supply In
Water Supply Out
Refrigeration Circuit
Water Circuit
Water Regulating
Valve
