4–32
Maintenance and Service Guide
Removal and replacement procedures
Display assembly
✎
The display assembly spare part kit includes two WLAN antenna transceivers and cables, two WWAN antenna
transceivers and cables, webcam, microphone, nameplate, and logo.
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Disconnect the wireless antenna cables from the WLAN module (see
) and the
).
6. Remove the following components:
a. Hard drive cover (see
b. Keyboard (see
)
c. Switch cover (see
)
d. Speaker assembly (see
Description
Spare part number
13.4-inch AntiGlare display assemblies for use only with dv3-2000 computer models:
■
For use only with computer models with black trim
530785-001
■
For use only with computer models with white trim
530787-001
13.4-inch BrightView display assemblies for use only with dv3-2000 computer models:
■
For use only with computer models with black trim
531787-001
■
For use only with computer models with blue trim
538659-001
■
For use only with computer models with white trim
531793-001
13.3-inch BrightView display assemblies:
■
For use only with computer models with black trim
531786-001
■
For use only with computer models with blue trim
538658-001
■
For use only with computer models with white trim
531792-001
Touch screen display assemblies:
■
13.4-inch display assembly for use only with dv3-2000 computer models with blue trim
576316-001
■
13.3-inch LED display assembly for use only with dv3-2300 computer models with
blue trim
591414-001
■
13.3-inch display assembly
595584-001
