Removal and replacement procedures
Maintenance and Service Guide 4–23
Optical drive
✎
The optical drive spare part kit includes an optical drive bezel and bracket.
Before removing the optical drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
4. Remove the battery (see “Battery” on page 7 ).
Remove the optical drive:
1. Position the computer with the right side toward you.
2. Remove the Phillips PM2.0×8.0 screw 1 that secures the optical drive to the computer.
3. Insert a thin tool, such as a paper clip 2, into the release access. (The optical drive disc tray is partially ejected
from the optical drive.)
4. Use the disc tray frame to slide the optical drive 3 out of the computer.
Description Spare part number
For use only with dv3-2000 computer models:
Blu-ray ROM DVD±R/RW SuperMulti DL Drive with LightScribe 530800-001
Blu-ray ROM DVD±R/RW SuperMulti DL Drive 530799-001
DVD±RW and CD-RW SuperMulti Double-Layer Drive with LightScribe 530798-001
For use only with dv3-2300 computer models:
Blu-ray ROM DVD±R/RW SuperMulti DL Drive with LightScribe 591425-001
DVD±RW and CD-RW SuperMulti Double-Layer Drive with LightScribe 591424-001
