Removal and replacement procedures
Maintenance and Service Guide 4–49
Bluetooth module
✎
The Bluetooth module spare part kit does not include a Bluetooth module cable. The Bluetooth module cable is
available using spare part number 531811-001 for dv3-2000 computer models and 591417-001 for dv3-2300
computer models.
Before removing the Bluetooth module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
4. Remove the battery (see “Battery” on page 7 ).
5. Remove the following components:
a. Hard drive (see “Hard drive” on page 8 )
b. Optical drive (see “Optical drive” on page 23 )
c. Keyboard (see “Keyboard” on page 25 )
d. Switch cover (see “Switch cover” on page 29 )
e. Speaker assembly (see “Speaker assembly” on page 31 )
f. Display assembly (see “Display assembly” on page 32 ).
g. Top cover (see “Top cover” on page 44 ).
Remove the Bluetooth module and cable:
1. Disconnect the Bluetooth module cable 1 from the system board.
2. Remove the Bluetooth module cable from the clips 2 built into the base enclosure.
3. Remove the Bluetooth module and cable 3.
Reverse this procedure to install the Bluetooth module.
Description Spare part number
Bluetooth module for use only with dv3-2000 computer models 483113-001
Bluetooth module for use only with dv3-2300 computer models 537921-001
