Illustrated parts catalog
Maintenance and Service Guide 3–35
589611-001 Switch cover for use with dv3-2000 computer models with blue trim
591412-001 System board for use with dv3-2300 computer models equipped with UMA graphics (includes
replacement thermal material)
591413-001 System board for use with dv3-2300 computer models equipped with discrete graphics (includes
replacement thermal material)
591414-001 13.3-inch touch screen LED display assembly for use only with dv3-2300 computer models (includes
2 WLAN antenna transceivers and cables, 2 WWAN antenna transceivers and cables, webcam,
microphone, nameplate, and logo)
591417-001 Bluetooth cable for use with only dv3-2300 computer models
591421-001 250-GB, 7200-rpm hard drive for use only with dv3-2300 computer models (includes hard drive
connector and hard drive bracket)
591422-001 320-GB, 7200-rpm hard drive for use only with dv3-2300 computer models (includes hard drive
connector and hard drive bracket)
591423-001 500-GB, 7200-rpm hard drive for use only with dv3-2300 computer models (includes hard drive
connector and hard drive bracket)
591424-001 DVD±RW and CD-RW SuperMulti Double-Layer Drive with LightScribe for use only with dv3-2300
computer models
591425-001 Blu-ray ROM DVD±R/RW SuperMulti DL Drive with LightScribe for use only with dv3-2300 computer
models
591429-001 Audio board for use with dv3-2300 computer models (includes cable)
591430-001 Fan/heat sink assembly for use only with dv3-2300 computer models equipped with UMA graphics
memory (includes replacement thermal material)
591431-001 Fan/heat sink assembly for use only with dv3-2300 computer models equipped with discrete
graphics memory (includes replacement thermal material)
591432-001 Switch cover for use only with dv3-2300 computer models with black trim (includes power button
board and cable)
591433-001 Switch cover for use only with dv3-2300 computer models with white trim (includes power button
board and cable)
591434-001 Switch cover for use only with dv3-2300 computer models with blue trim (includes power button
board and cable)
591436-001 Top cover with fingerprint reader board with molded finish for use only with dv3-2300 computer
models with black trim (includes TouchPad on/off board and cable, TouchPad button board and
cable, TouchPad board and cable, and fingerprint reader board cable)
591437-001 Top cover without fingerprint reader board with molded finish for use only with dv3-2300
computer models with black trim (includes TouchPad on/off board and cable, TouchPad button board
and cable, and TouchPad board and cable)
591438-001 Top cover with fingerprint reader board with molded finish for use only with dv3-2300
computer models with white trim (includes TouchPad on/off board and cable, TouchPad button board
and cable, TouchPad board and cable, and fingerprint reader board cable)
591439-001 Top cover without fingerprint reader board with molded finish for use only with dv3-2300 computer
models with white trim (includes TouchPad on/off board and cable, TouchPad button board and
cable, and TouchPad board and cable)
591440-001 Top cover without fingerprint reader board for use only with dv3-2300 computer models with blue trim
(includes TouchPad on/off board and cable, TouchPad button board and cable, and TouchPad board
and cable)
592517-001 Top cover with fingerprint reader board for use only with dv3-2300 computer models with blue trim
(includes TouchPad on/off board and cable, TouchPad button board and cable, TouchPad board and
cable, and fingerprint reader board cable)
Continued
Spare part number Description
