Chapter 2 Operator Panel 41
Chapter 2
Library Status
The Library Status screen is an information-only screen. It is the first screen to
appear on the operator panel after an IPL.
Figure 7 on page 41 shows an example Library Status screen. (For a list of
drive status messages, see Drive Status on page 98.)
Figure 7 Library Initial Status Screen
HP A5597A (CODE VERSION
X.XX.XX)
Library type and firmware version
CAP (A) CLOSED CAP status
LIBRARY READY Library status
WEB ENABLED Remote access is available through the
Web-Based Library Administrator
(WBLA)
COLUMN 0 The status of each drive in a specified
drive column
HP A5597A(CODE VER X.XX.XX)*
CAP CLOSED
LIBRARY READY
WEB ENABLED
COLUMN 0
00 BUSY
01 BUSY
02 LOADING
03 LOADING
04 EMPTY
05 EMPTY
06 EMPTY
07 ---
08 ---
09 ---
