Chapter 2 Operator Panel 37
Chapter 2
Table 3 Operator Panel Display, Controls, and Indicators (continued from
Figure 6 on page 36 )
1 Service Required indicator is steadily red
when human intervention is required.
7 [RESET] button, located behind the right front
door, starts an IPL.
2 Library Active indicator flashes green when
the library is operational.
8 Arrow down button moves the cursor down
the display screen or decrements an
underscored value.
3 Open indicator is steadily amber when the
CAP is open for you to import or remove
cartridges.
9 [SELECT] button selects an item on a menu; it
also saves the currently underscored value
and moves the cursor to the next field.
4 [CAP A] open button rotates CAP A for you
to access the magazines.
10 Arrow up button moves the cursor up the
display screen; it also increments a value
underscored on the screen.
5 [CAP B] open button rotates CAP B for you
to access the magazines.
11 Graphic display screen shows current
information, FSCs, and allows input from
menus.
6 [MENU] button initially places you into the
Main Menu screen; subsequently, it returns
you to a previously selected screen.
