Heat & Glo • Gateway • 288-900 Rev. W • 10/08 18
H
V
H
1 H
2
H
3
3 FT.
MAXIMUM
Figure 5.7 PV-Flex only
H
V
H
1 H
2
H
3
H
4
3 FT.
MAXIMUM
Figure 5.6 PV-Flex only
VENTING WITH
FOUR 90º BENDS
V DOWN
3 Ft. Max. (91.4 cm)
H + H
1
+ H
2
+ H
3
32 Ft. Max. (9.8 m)
V + H + H
1
+ H
2
+ H
3
35 Ft. Max. (10.7 m)
Note: Only horizontal
venting allowed after
downward venting run.
Note: Only horizontal
venting allowed after
downward venting run. VENTING WITH
FIVE 90º BENDS
V DOWN
3 Ft. Max. (91.4 cm)
H + H
1
+ H
2
+ H
3
+ H
4
30 Ft. Max. (9.1 m)
V + H + H
1
+ H
2
+ H
3
+ H
4
33 Ft. Max. (10.1 m)
