Heat & Glo • Gateway • 288-900 Rev. W • 10/08 17
Figure 5.5 PV-Flex only
VENTING WITH
TWO 90º BENDS
V DOWN
3 Ft. Max. (91.4 cm)
H + H
1
35 Ft. Max. (10.7 m)
V + H + H
1
38 Ft. Max. (11.6 m)
H
1
V
H
3 FT.
MAXIMUM
V
H
3 FT.
MAXIMUM
H
2 H
1
Figure 5.4 PV-Flex only
H
H
1
V
VENTING WITH
TWO 90º BENDS
V UP
35 Ft. Max. (10.7 cm)
H + H
1
35 Ft. Max. (10.7 m)
V + H + H
1
38 Ft. Max. (11.6 m)
Note: Only horizontal
venting allowed after
downward venting run.
Note: Only horizontal
venting allowed after
downward venting run.
VENTING WITH
THREE 90º BENDS
V DOWN
3 Ft. Max. (91.4 cm)
H + H
1
+ H
2
35 Ft. Max. (10.7 m)
V + H + H
1
+ H
2
35 Ft. Max. (10.7 m)
