Connections
65
En
Rear panel
(1) Powered amplifier, powered speakers, etc.,
(2) Powered amplifier (for booth monitor), powered speakers, etc.,
(3) Home stereo, powered amplifier, powered speakers, etc.,
(4) DMX cable (XLR 3 pin), (5) Lighting fixture
•
Be sure to use the
[MASTER 1]
output terminals for a balanced
output.
If these terminals are connected to an unbalanced input (such as
RCA) using an XLR to RCA converter cable (or a converter adapter),
etc., sound quality may decrease or unwanted noise may occur.
•
To connect to an unbalanced input (such as RCA), use the
[MASTER
2]
output terminals.
•
Be careful not to accidentally insert the power cord plug of another
unit or device into one of the
[MASTER 1]
output terminals.
•
Never connect devices capable of supplying phantom power to the
[MASTER 1]
output terminals.
R L
