Connections
63
En
Connection examples
Connecting input terminals
Rear panel
(1) Turntable, (2) Multi player, (3) Microphone, (4) PC/Mac, (5) Portable
audio device, (6) AC adapter, (7) Power cord, (8) Connection to a
power outlet
When connecting a turntable to the
[CH3]
/
[CH4]
input terminals, set
the
[LINE/PHONO]
switch beside the terminals to
[PHONO]
.
When connecting a multi player to the
[CH3]
/
[CH4]
input terminals,
set the
[LINE/PHONO]
switch beside the terminals to
[LINE]
.
R L
R L
R L
R L
