16:10 Aspect Ratio Image or Screen

Screen or image size Projection distance (1)

Offset from top of
projector (2)

Offset from top of
projector (3)

80 inches (203.2 cm)

7.3 inches (18.5 cm)

8.1 inches (20.6 cm)

50.5 inches (128.3 cm)

85 inches (215.9 cm)

8.6 inches (21.8 cm)

8.8 inches (22.3 cm)

53.8 inches (136.7 cm)

90 inches (228.6 cm)

9.9 inches (25 cm)

9.5 inches (24 cm)

57.1 inches (145.1 cm)

100 inches (254 cm)

12.4 inches (31.5 cm)

10.7 inches (27.3 cm)

63.8 inches (162 cm)

111 inches (281.9 cm) 15.2 inches (38.6 cm)

12.2 inches (31 cm)

71.1 inches (180.5 cm)

Parent topic:

Projector Placement

Projector Connections

See these sections to connect the projector to a variety of projection sources.

Caution:

If you will use the projector at altitudes above 4921 feet (1500 m), turn on

High Altitude Mode

to ensure the projector's internal temperature is regulated properly.

Caution:

Check the shape and orientation of the connectors on any cable you plan to connect. Do not

force a connector into a port if it does not fit. The device or your projector could be damaged or could
malfunction.

Parent topic:

Setting Up the Projector

Related references

Connecting to an HDMI Video Source

If your video source has an HDMI port, you can connect it to the projector using an optional HDMI cable.
