22
Projection Distance
The distance at which you place the projector from the screen determines the approximate size of the
image. The image size increases the farther the projector is from the screen, but can vary depending on
the zoom factor, aspect ratio, and other settings.
Use the tables here to determine approximately how far to place the projector from the screen based on
the size of the projected image. (Conversion figures may have been rounded up or down.)
You can also use the Projection Distance Calculator here (U.S.), here (Canada), or here (Caribbean).
1 Projection distance (from image to rear of projector)
2 Distance from projector to base of image
3 Distance from projector to top of image
16:9 Aspect Ratio Image or Screen
Screen or image size Projection distance (1) Offset from top of
projector (2) Offset from top of
projector (3)
61 inches (154.94 cm) 1.3 inches (3.22 cm) 5 inches (12.7 cm) 34.9 inches (88.7 cm)
70 inches (177.8 cm) 3.4 inches (8.6 cm) 6.1 inches (15.5 cm) 40.4 inches (102.7 cm)
75 inches (190.5 cm) 4.6 inches (11.6 cm) 6.7 inches (17 cm) 43.5 inches (110.4 cm)
80 inches (203.2 cm) 5.8 inches (14.6 cm) 7.3 inches (18.6 cm) 46.5 inches (118.2 cm)
