9
Preparations
Chapter 02
Installation
Attaching the Stand
―
Disassembly is the reverse order of assembly.
S27AG50* / S32AG50* / S27AG52* / S32AG52*
1
Put the stand base onto the stand neck as the
direction shown in the figure. Check that the stand
neck is firmly connected.
2 3 4 5
Tightly fasten the connecting screw at
the bottom of the stand base. Fasten
the large screw in the middle for
assembly. Push the assembled stand into the main body in the direction of the arrow as
shown in the figure. Disassemble the COVER-REAR TOP. Assemble the COVER-REAR TOP to the stand neck
as shown in the figure.
6 7 8
Rotate the COVER-REAR TOP clockwise. Stand up the monitor as shown in the
figure. After installing the stand, place the
product upright. Caution
Do not arbitrarily remove the panel film. If not
observed, the warranty service may be restricted.
