Samsung G52A 32" 16:9 165 Hz IPS Gaming Monitor - Manual (Page 25)

25
Tidying Up the Connected Cables
―
Refer to "Attaching the Stand ( P.11 )" for more information on how to organize cables for the S49AG95*N model.
S27AG50* / S32AG50* / S27AG52* / S32AG52*
1 1 1 2
Connect the corresponding cables. Pull the right side of the HOLDER-STAND CABLE
to remove from the stand. The left side of the
HOLDER-STAND CABLE can be damaged when
pulled forcibly.
1 3
Put both cables in the cable holder on the stand
(HOLDER-STAND CABLE) to organize the cables,
as shown in the figure.
Assembly is complete.
S28AG70*
1 1 2
Connect the corresponding cables. Arrange the cables against the bend tendency of
the cables and pull the cables out of the COVER-
REAR SUB grooves.
1 3 1 4
Pull the right side of the HOLDER-STAND CABLE
to remove from the stand. The left side of the
HOLDER-STAND CABLE can be damaged when
pulled forcibly. Put both cables in the cable holder on the stand
(HOLDER-STAND CABLE) to organize the cables,
as shown in the figure.
Assembly is complete.
