Cable, CompactFlash and Accessory Specifications
A-2
Cable, CompactFlash and Accessory Specifications
Refer to the following table for specifications of cables, CompactFlash and accessories for the XSR.
This equipment can all be obtained separately from Enterasys Networks or through any computer
supply retailer.
Power
Consumption Typical values: Motherboard: 75 watts (maximum)
Serial NIM card: 4 watts
T1/E1/ISDN-PRI NIM card: 3 watts
ISDN BRI-S/T NIM card: 1 watt
Internal Power
Supplies (2) Type Dual universal (110/220 VAC) load-sharing, redundant units
Input AC Voltage
& Frequency 100-125 Vac, 1.7A
200-240 Vac, 0.85A
50/60Hz
I/O Interfaces Onboard (LAN) 2 10/100/1000BaseT Ethernet ports with RJ-45 copper connectors,
10/100/1000 or Mini-GBIC optical connector
RS-232 COM serial port with DB-9 connector
NIM (WAN) Slots Dual or Quad synch/asynch Serial ports with DB-type connector also
supporting X.21, V.35, EIA-449, EIA-232/530 and combined V.35/
EIA-232/530 DTE interfaces with required adapter.
Single, dual, or quad T1/E1 RJ-48C port(s) with integral CSU/DSU.
Full-channel, fractional or unchannelized.
Single port T3/E3 un-channelized NIM with BNC connectors
I/O Interfaces NIM (WAN) Slots Dual or quad port BRI/PRI S/T NIM (RJ-45) or U NIM with RJ-45 or
RJ-49C connectors, respectively.
Dual or quad port BRI/PRI S/T NIM (RJ-45) or U NIM with RJ-45 or
RJ-49C connectors, respectively.
Single port Annex A/C or B ADSL NIM with RJ-11 connector.
Includes CompactFlash card.
NIM (LAN or
WAN) Single port 10/100Base-T Copper or 10/100Base-F Fiber-optic
Ethernet NIM with RJ-45 connector or MT-RJ multi-mode interface,
respectively.
Chassis LEDs 14 Display port and system status, warn of Flash upgrade
Table A-1 XSR Hardware Specifications (continued)
Category Parameters
Table A-2 XSR Cabling/Accessory Guide
Part Description Connector Part # Function
6’ DB-9 null modem cable DB-9, male N/A from Enterasys COM link to serial line
.58, 1, 2, 3, 5, or 10 meter 10/100BaseT
straight-through or cross-over cable RJ-45 N/A from Enterasys Ethernet link to hub/switch or
PC/uplink port
