Menu List (continued)
*3 If a key-compositing effect (W-LUMIKEY, B-LUMIKEY, CHROMAKEY) is on, the border and shadow of the subscreen will not be shown.
Main menu
(First level)
Sub-menu
(Second level)
Value
(The factory setting is printed in bold characters.)
See
page
Advanced settings P in P effect are made
here.
* For details on the factory settings, refer
to p. 89.
Adjusts the horizontal position of the
subscreen
0–600 (Changes according to the
subscreen size.) p. 44
Adjusts the vertical position of the subscreen
0–207 (Changes according to the
subscreen size.)
Adjusts the size of the subscreen with the
aspect ratio fixed at 4:3
0–220 (Changes according to the
subscreen size.)
Adjusts the horizontal size of the subscreen
0–220 (Changes according to the
subscreen position.)
Adjusts the vertical size of the subscreen
0–220 (Changes according to the
subscreen position.)
Adjusts the border width of the subscreen
0–15
Specifies the border color of the subscreen
0–15
Adjusts the shadow length for the subscreen
0–15
Specifies the shadow color for the subscreen
0–15
Adjusts the trimming region for the subscreen
0–30
Returns the sub-menu settings to the factory-
set state
--- p. 34
Advanced settings key composite effects
are made here. Adjusts the level for luminance keying
(extract white)
0– 128 –255 p. 47
Adjusts the soft edge level for luminance
keying (extract white)
1– 14 –15
Adjusts the level for luminance keying
(extract black)
0– 128 –255
Adjusts the soft edge level for luminance
keying (extract black)
1– 14 –15
Specifies the key color for chroma keying
Blue-Magenta, Blue-Cyan , Red-Magenta,
Red-yellow, Magenta-Red, Magenta-Blue,
Cyan-Green, Green-Cyan, Green-Red,
Cyan-Blue, Yellow-Green, Yellow-Red
Adjust the key level for chroma keying
0– 128 –255
Adjust the soft edge level for chroma keying
1– 14 –15
Adjusts the threshold value between light and
dark when using the “052: SILHOUETTE1”–
“060: SILHOUETTE]” effects
0– 128 –255
Returns the sub-menu settings to the factory-
set state
--- p. 34
PinP1 Setup
PinP2 Setup
PinP3 Setup
PinP4 Setup
PinP5 Setup
PinP6 Setup
PinP7 Setup
PinP8 Setup
PinP-Hposi
PinP-Vposi
PinP-4:3 HVsize
PinP-Hsize
PinP-Vsize
PinP-Border *3
PinP-BColor *3
PinP-Shadow *3
PinP-SColor *3
PinP-Trimming
PinP-Reset
Key Setup White-LumiKey Level
White-LumiKey Edge
Black-LumiKey Level
Black-LumiKey Edge
ChromaKey Color
ChromaKey Level
ChromaKey Edge
Silhouette Level
Key Reset
