Extron electronic FOX 2G Tx - Manual (Page 40)

FOX 2G Tx/Rx A
V • Configuration
Configuration, cont’d
3-12
Command ASCII Command
(host to unit)
Response
(unit to host)
Additional description
Auto Image
Trigger 55*2# Img
] Returns video adjustments (color, contrast,
tint, and brightness) to default values (64)
Test Pattern
Color bars 1J
Tst1
]
Sets color bars test pattern on (
X(
)
0 = test pattern off 1 = color bars
2 = grayscale 3 = alternating pixels
Grayscale 2J Tst2
] Sets grayscale test pattern on
Alternating pixels 3J Tst3
] Sets alternating pixels test pattern on
Off 0J Tst0
] Sets test pattern off
View current test pattern status J X(] Displays current test pattern status
Link #2 Transmission
Disable 66*0*0# Rle*0*0
]
Disables link #2 (
X1)
)
0 = disables link #2 (receiver to transmitter)
1 = enables link #2
2 = enables receiver daisy chain mode
Enable 66*0*1# Rle*0*0
] Enables link #2
Daisy chain 66*0*2# Rle*0*0
] Enables receiver daisy chain mode
View current Link #2 status 66*0# 0*
X1)] Displays current link #2 status
This command will only be available on the
reciever unit; the transmitter will respond
with an E14 error code.
