FOX 2G Tx/Rx A
V • Configuration
Configuration, cont’d
3-10
Command ASCII Command
(host to unit)
Response
(unit to host)
Additional description
Output video format
Specify output setting 6*
X$
# Syn
X$]
Sets format of output video signal (
X$
)
0 = Follow input type 6 = Component
7 = S-Video 8 = Composite
View current output setting 6# X$] Displays current output video format
Memory Presets
Recall Preset X1#
. Rpr
X1#]
A period (.) follows
X1#
in the command.
Recalls memory preset (
X1#
) from 1 to 30
Save Preset X1#
, Spr
X1#]
A comma (,) follows
X1#
in the command.
Saves memory preset (
X1#
)
Audio mute
Enable audio mute 1Z Amt1
]
Mutes audio (
X#
)
0 = Disables audio mute
1 = Enables audio mute
Disable audio mute 0Z Amt0
] Un-mutes audio
View current audio mute status Z X#] Displays current audio mute status
Audio gain and attenuation
Specify gain value X%
G Aud
X%] Sets value of audio gain. Upper case "G"
only for configuring gain
(
X%
from 0 to 10)
Specify attenuation value X^
g Aud
X^] Sets value of audio attenuation. Lower case
"g " only for configuring attenuation
(
X^
from 0 to -18)
