1-2

CVDA 6 EQ MX • Specifications

Specifications — CVDA 6 EQ MX Distribution Amplifier

Video

Equalization .................................. 0dB to +4dB (over a 0.5 MHz to 8 MHz range)
Gain ................................................ -6dB to +6dB
Bandwidth ..................................... 30 MHz (<±0.5dB)
Differential phase error .............. 1º at 3.58 MHz
Differential gain error ................. 0.05% at 3.58 MHz
Crosstalk ....................................... <-50dB at 3.58 MHz

Video input

Number/signal type ................... 1 NTSC, PAL, SECAM composite video
Connectors ................................... 1 BNC female
Nominal level ............................... 1V p-p for composite video
Minimum/maximum levels ....... Analog: 0.4V to 2.0V p-p with no offset at unity gain
Impedance .................................... 75 ohms
Return loss .................................... <-40dB minimum, 0 to 10 MHz
Maximum DC offset .................... 1.0V

Video output

Number/signal type ................... 7 composite video .... 6 amplified for distribution

1 buffered loop-through

Connectors ................................... 7 BNC female
Nominal level ............................... 1V p-p for composite video
Minimum/maximum levels ....... 0.4V to 2.0V p-p
Impedance .................................... 75 ohms
DC offset ....................................... ±20mV maximum with input at 0 offset

Sync

Standards ...................................... NTSC 3.58, NTSC 4.43, PAL, SECAM

General

Power ............................................ 100VAC to 240VAC, 50/60 Hz, 12 watts, internal, autoswitchable
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing

Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing

Rack mount .................................. Yes, with optional 1U rack shelf, part #60-190-01
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.6" H x 8.7" W x 9.4" D (1U high, half rack width)

4.1 cm H x 22.1 cm W x 23.9 cm D
(Depth excludes connectors.)

Product weight ............................. 2.9 lbs (1.3 kg)
Shipping weight ........................... 5 lbs (2.3 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A
Warranty ....................................... 3 years parts and labor

Specifications are subject to change without notice.


7.40-031303-D2-112012
