Xld281 rigging dimensions and weights, Figure 4a – Electro-Voice X-Line Very Compact (XLVC) User Manual
Page 9
ELECTRO-VOICE
®
X-Line Very Compact
TM
Rigging Manual
Figure 4a:
XLD281 Rigging Dimensions and Weights
Front View (With Grille)
Rear View
Side View
Hole Detail
Scale 3:1
1°
Hole
3°
Hole
5°
Hole
7°
Hole
0°
Hole
2°
Hole
4°
Hole
6°
Hole
8°
Hole
9°
Hole
10°
Hole
-4°
Hole
-2°
Hole
0°
Hole
2°
Hole
4°
Hole
Full Range Only
Subwoofer Only
Weight: 48 lb (21.8 kg)
LF1
HF
LF2
LF2
HF
LF1
8
