Electro-Voice XI-1122MHA/64F User Manual
Technical specifications: general description, Key features
Technical Specifications:
General Description:
Xi-1122MHA/64F
12-Inch Two-Way,
Half-Height, Mid-High 60° x 40°
Sound Reinforcement System
Key Features:
•
Compact/High-Level, Two-Way Design
•
ND12A 12” Neodymium Mid-Bass Driver
(60° x 40° Coverage)
•
Coaxially-Mounted ND6-16 3” Diaphragm HF
Compression Driver for Very High Output
•
Fully Rotatable HF Section for Vertical or
Horizontal Suspension
•
Ring-Mode Decoupling / RMD
TM
•
Built-In L-Track Rigging
•
Available in Black or White
•
Footprint Identical to Xi-1153A, Xi-1183A,
Xi-2153A, Xi-1191A, Xi-2181A, and Xi-2122MHA
The Electro-Voice
®
Xi-1122MHA/64F is a mid-high, two-way,
biamp system designed for medium- to long-throw
applications. The ND6-16 high-frequency driver/horn
combination is fully “shrouded” to preserve midbass wave-
front detail. The ND12A 12-inch, application-specific mid-
bass driver features RMD™ and a 60° x 40° horn. The 60° x
40° coverage pattern offers precise pattern control, and
would be well suited for front-of-house, front-fill, side-fill and
delay applications. When very high levels are desired we
suggest augmenting with the Xi-1191A. Its high-frequency
horn/driver section is rotatable to provide proper coverage
for vertical or horizontal system installations. The Xi-
1122MHA/64F is a two-way system that requires an active
electronic crossover. Both the Electro-Voice Dx38 and Klark
Teknik DN9848 digital controllers are recommended for
signal control. The Electro-Voice P3000 amplifier is
recommended for powering the MB, and the P1200 is
recommended for powering the HF of the Xi-1122MHA/46F.
