ELECTRO-VOICE ® X-Line Very Compact TM Rigging Manual 42
Figure 14b:
XLE181 Complex Structural Ratings
+ ∅ °
- 5 °
MAX
+ 5 °
MAX
- ∅ °
+ ∅ °
- 5 °
MAX
+ 5 °
MAX
Xle181 Hinge Bar Working-Load-Limit Structural Ratings
0 lbs
100 lbs
200 lbs
300 lbs
400 lbs
500 lbs
-180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180
Angle (Degrees)
W
o
rk
ing-
Loa
d Li
m
it
(
lbs
)
0 kg
100 kg
200 kg
W
o
rk
ing-
Loa
d Li
m
it
(
kg)
Xle181 Swing Arm Working-Load-Limit Structural Ratings
0 lbs
100 lbs
200 lbs
300 lbs
400 lbs
500 lbs
-180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180
Angle (Degrees)
W
o
rk
ing-
Loa
d Li
m
it
(
lbs
)
0 kg
100 kg
200 kg
W
o
rk
ing-
Loa
d Li
m
it
(
kg)
Total Column Weight
Working-Load Limit
720 lb (327 kg)
XLE181 Hinge Bar Structural Ratings
- ∅ °
XLE181 Swing Arm Structural Ratings
XLE181 Overall Enclosure Structural Ratings
