Xs212 rigging dimensions and weights, Figure 4c – Electro-Voice X-Line Very Compact (XLVC) User Manual
Page 11
ELECTRO-VOICE
®
X-Line Very Compact
TM
Rigging Manual
Figure 4c:
XS212 Rigging Dimensions and Weights
Front View
Rear View
Side View (With Grille)
Hole Detail
Scale 3:1
1°
Hole
3°
Hole
20/4°Up
Hole
18/2°Up
Hole
16/0°
Hole
14/2°
Hole
12/4°
Hole
5°
Hole
10°
Hole
8°
Hole
6°
Hole
4°
Hole
2°
Hole
0°
Hole
Sub/Full Range
Subwoofer Only
Weight: 90 lb
(40.8 kg)
10
