Xle181 loudspeaker system, Xs212 loudspeaker system, Figure 1b – Electro-Voice X-Line Very Compact (XLVC) User Manual
Page 5: Figure 1c
ELECTRO-VOICE
®
X-Line Very Compact
TM
Rigging Manual
4
Figure 1b:
XLE181 Loudspeaker System
Figure 1c:
XS212 Loudspeaker System
Front View (Without Grille)
Top View
Side View
Rear View
20.30in
(516mm)
14.52in
(369mm)
9.90in
(251mm)
7.41in
(188mm)
Front View
Top View
Side View (Without Grille)
Rear View
28.58in
(726mm)
14.90in
(378mm)
20.00in
(508mm)
HF
LF
LF
HF
