ELECTRO-VOICE ® X-Line Very Compact TM Rigging Manual 43
Figure 14c:
XS212 Complex Structural Ratings
+ ∅ ° + 5 °
MAX
- 5 °
MAX
- ∅ ° + ∅ °
- 5 °
MAX
+ 5 °
MAX
Xs212 Hinge Bar Working-Load-Limit Structural Ratings
0 lbs
100 lbs
200 lbs
300 lbs
400 lbs
500 lbs
-180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180
Angle (Degrees)
W
o
rk
ing-
Loa
d Li
m
it
(
lbs
)
0 kg
100 kg
200 kg
W
o
rk
ing-
Loa
d Li
m
it
(
kg)
Xs212 Swing Arm Working-Load-Limit Structural Ratings
0 lbs
100 lbs
200 lbs
300 lbs
400 lbs
500 lbs
-180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180
Angle (Degrees)
W
o
rk
ing-
Loa
d Li
m
it
(
lbs
)
0 kg
100 kg
200 kg
W
o
rk
ing-
Loa
d Li
m
it
(
kg)
Total Column Weight
Working-Load Limit
900 lb (408 kg)
XS212 Hinge Bar Structural Ratings
- ∅ °
XS212 Swing Arm Structural Ratings
XS212 Overall Enclosure Structural Ratings
