Motherboard Information
Network Application Platforms
Chapter 3
PCIEC3
PIN NO.
FUNCTION
PIN NO.
FUNCTION
B1
+12V
A1
PRSNT1#
B2
+12V
A2
+12V
B3
+12V
A3
+12V
B4
GND
A4
GND
B5
SMCLK
A5
JTAG2
B6
SMDAT
A6
JTAG3
B7
GND
A7
JTAG4
B8
+3.3V
A8
JTAG5
B9
JTAG1
A9
+3.3V
B10
3.3VAUX
A10
+3.3V
B11
WAKE#
A11
PERST#
B12
BYPASS0 Mode
A12
GND
B13
GND
A13
REFCLKA+
B14
EX_CPUPETP0
A14
REFCLKA-
B15
EX_CPUPETN0
A15
GND
B16
GND
A16
EX_CPUPERP0
B17
LANM0_LATCH_H
A17
EX_CPUPERN0
B18
GND
A18
GND
B19
EX_CPUPETP1
A19
BYPASS1 Mode
B20
EX_CPUPETN1
A20
GND
B21
GND
A21
EX_CPUPERP1
B22
GND
A22
EX_CPUPERN1
B23
EX_CPUPETP2
A23
GND
B24
EX_CPUPETN2
A24
GND
B25
GND
A25
EX_CPUPERP2
B26
GND
A26
EX_CPUPERN2
B27
EX_CPUPETP3
A27
GND
B28
EX_CPUPETN3
A28
GND
B29
GND
A29
EX_CPUPERP3
B30
REFCLK1A+
A30
EX_CPUPERN3
B31
REFCLK1A-
A31
GND
B32
GND
A32
LANM1_LATCH_H
B33
SBPETP3
A33
LANM1_LATCH_L
B34
SBPETH3
A34
GND
B35
GND
A35
SBPERP3
B36
GND
A36
SBPERN3
B37
SBPETP2
A37
GND
B38
SBPETN2
A38
GND
B39
GND
A39
SBPERP2
B40
GND
A40
SBPERN2
B41
SBPETP1
A41
GND
B42
SBPETN1
A42
GND
B43
GND
A43
SBPERP1
B44
GND
A44
SBPERN1
B45
SBPETP0
A45
GND
B46
SBPETN0
A46
GND
B47
GND
A47
SBPERP0
B48
LANM0_LATCH_L
A48
SBPERN0
B49
GND
A49
GND
