Motherboard Information

Network Application Platforms

Chapter 3

Mini-PCI Connector (PCIB1): The Mini-PCI slot enables a

Mini-PCI expansion module to be connected to the

board.

ATX Power Connector(ATX1, ATX2): These 24-pin and

8-pin connectors are for connecting ATX power
supply plugs. Find the proper orientation when
inserting the plugs, for the supply plugs are
designed to fit these connectors in only one
orientation.

AT Mode Power Button Connector (J15): It is for connecting

the power switch in AT mode

AT Mode Jumper(J17): It is for adjusting the jumper setting

for the system power to be in ATX mode if AT Mode

Power Button Connector (J15) is used.

111

M O D _ A U D I O _

MON

112

RESERVED

113

AUDIO_GND

114

GROUND

115

SYS_AUDIO_OUT

116

SYS_AUDIO_IN

117

SYS_AUDIO_OUT

GND118

118

SYS_AUDIO_IN GND

119

AUDIO_GND

120

AUDIO_GND

121

RESERVED

122

MPCIACT

123

+5V

124

+3.3 STBY

1
2

Pin No.

Function

--

Normal (Default ATX Mode)

1-2

AT mode

1
2

Pin No.

Function

1

PS_ON#

2

GND

Pin No.

Function

1

GND

2

GND

3

GND

4

GND

5

+12V

6

+12V

7

+12V

8

+12V

5 6 7 8

( u p p e r )

1 2 3 4

( l o w e r )

Pin No.

Function

Pin NO.

Function

1

+3.3V

2

+3.3V

3

+3.3V

4

-12V

5

GROUND

6

GOUND

7

+5V

8

PSON-

9

GROUND

10

GROUND

11

+5V

12

GROUND

13

GROUND

14

GROUND

15

POWER GOOD

16

NC

17

STAND-BY 5V

18

+5V

19

+12V

20

+5V

21

+12V

22

+5V

23

+3.3V

24

GROUND

23
21
19
17
15
13
11

9
7
5
3
1

24
22
20
18
16
14
12
10

8
6
4
2

PIN NO.

FUNCTION

PIN NO.

FUNCTION

1

TIP

2

RING

3

8PMJ-3

4

8PMJ-1

5

8PMJ-6

6

8PMJ-2

7

8PMJ-7

8

8PMJ-4

9

8PMJ-8

10

8PMJ-5

11

LED1_GRNP

12

LED2_YELP

13

LED1_GRNN

14

LED2_YELP

15

CHSGND

16

RESERVED

17

INT-B

18

+5V

19

+3.3V

20

INT-A

21

RESERVED

22

RESERVED

23

GROUND

24

3.3VAUX

25

CLK

26

RST

27

GROUND

28

+3.3V

29

REO

30

GNT

31

+3.3V

32

GROUND

33

AD31

34

PME

35

AD29

36

RESERVED

37

GROUND

38

AD30

39

AD27

40

+3.3V

41

AD25

42

AD28

43

RESERVED

44

AD26

45

C_BE-3

46

AD24

47

AD23

48

IDSEL

49

GROUND

50

GROUND

51

AD21

52

AD22

53

AD19

54

AD20

55

GROUND

56

PAR

57

AD17

58

AD18

59

C_BE-2

60

AD16

61

IRDY

62

GROUND

63

+3.3V

64

FRAME

65

CLKRUN

66

TRDY

67

SERR

68

STOP

69

GROUND

70

+3.3V

71

PERR

72

DEVSEL

73

C_BE-1

74

GROUND

75

AD14

76

AD15

77

GROUND

78

AD13

79

AD12

80

AD11

81

AD10

82

GROUND

83

GROUND

84

AD9

85

AD8

86

C_BE-0

87

AD7

88

+3.3V

89

+3.3V

90

AD6

91

AD5

92

AD4

93

RESERVED

94

AD2

95

AD3

96

AD0

97

+5V

98

RESERVED-WIP

99

AD1

100

RESERVED-WIP

MINIPCI1

2 4 6 8 1 2 4

1 3 5 7 1 2 3
