19
Bios Settings
Chapter 4
Network Application Platforms
Primary /Secondary IDE Master and Slave Sub Menu
From the IDE Configuration screen, select one of the hard
disk drives to configure it, press to access the sub
menu for the primary/secondary IDE master and slave
drives. Use this screen to select options for the Primary
and Secondary IDE drives. Use the up and down
keys to select an item. Use the and keys
to change the value of the selected option. The settings
are described on the following pages. The screen for the
Primary IDE Master is shown at the right.
Type
This option sets the type of device that the AMIBIOS
attempts to boot from after the Power-On-Self-Test (POST)
has completed.
Option Description
Not Installed Set this value to prevent the BIOS from
searching for an IDE disk drive on the specified
channel.
Auto Set this value to allow the BIOS to automatically
detect the IDE disk drive type attached to the
specified channel. This setting should be used
if an IDE hard disk drive is attached to the
specified channel. This is the default setting.
CDROM This option specifies that an IDE CD-ROM drive
is attached to the specified IDE channel. The
BIOS will not attempt to search for other types
of IDE disk drives on the specified channe.
ARMD This option specifies an ATAPI Removable
Media Device.
This includes, but is not limited to:
• ZIP
• LS-120
LBA/Large Mode
LBA (Logical Block Addressing) is a method of addressing
data on a disk drive.
Option Description
Disabled Set this value to prevent the BIOS from using
Large Block Addressing mode control on the
specified channel.
Auto Set this value to allow the BIOS to automatically
detect the Large Block Addressing mode control
on the specified channel. This is the default
setting.
Block (Multi-Sector Transfer)
This option sets the block mode multi sector transfers
option.
