8-4 SMA America SB700U-11:SE3207
Specifications subject to change without notice.
Maximum Input Short
Circuit Current
18 A
Maximum Input Source Back-
feed Current to Input Source
15 A
Maximum Output Fault Current 15 A
Maximum Output
Overcurrent Protection
15 A
Synchronization In-Rush Current 3.6 A
DC Voltage Ripple Less than 10 %
Power Consumption 0.1 W nighttime, < 4 W in operation
Ambient Temperature Rating -13 °F ... +113 °C
-25 °C ... +45 °C
Enclosure NEMA 4X (IP65) (stainless steel)
Dimensions 12.70 W x 12.60 H x 7.10 D inches
(322 W x 320 H x 180 D mm)
Weight 35 lbs. (16 kg)
Compliance UL1741, UL 1998, IEEE 929, IEEE 1547,
IEEE C37.90.1, IEEE C62.41.2 (test
conditions 2 kV / 1 kA), FCC Part 15 A & B
