SMA SB 700U - Manual (Page 81)

SB700U-11:SE3207 SMA America 8-3
Specifications
Inverter Technology Sine-wave, current source,
high frequency PWM
AC Input Voltage 106 - 132 @ 120 V AC
AC Input Frequency 59.3 - 60.5 (60 Hz)
Peak Power Tracking Voltage 125 - 200 V DC /
100 - 160 V DC /
77 - 120 V DC
Range of Input
Operating Voltage
125 - 250 V DC /
100 - 200 V DC /
77 - 150 V DC
Maximum DC Power 780 W /
670 W /
510 W
Maximum AC Continuous
Output Power
700 W /
600 W /
460 W
Current THD Less than 3%
Output Power Factor > 0.99 @ nominal power
Peak Inverter Efficiency 93.6 % /
93.3 % /
92.4 %
CEC Weighted Efficiency 91.5 %
Cooling Convection cooling (no fan)
PV Start Voltage 150 V DC/
125 V DC /
95 V DC
Maximum AC Continuous
Output Current
6.6 A /
5.7 A /
4.3 A
Maximum DC Input Current 7 A
