7-4 SMA America SB700U-11:SE3207
K1-Close
K1-Open
K2-Open Relay test failed. Contact SMA for assistance. Error
MSD-Time-
out BFR or SSR controller failure Error
MSD-VAC
MSD-FAC
MSD-Idif Internal measurement comparison error: The Sunny Boy
measured values of BFR and SRR are too different from
each other. Error
OFFSET Grid monitoring self-test failed. Error
ROM The internal test of the Sunny Boy Control system firmware
failed. Contact SMA in case you observe this failure often. Error
Shut-Down Internal over current continuous Error
Vac-Bfr
Vac-Srr The AC grid voltage is exceeding the permissible range.
(„Bfr“ or „Srr“ is an internal message and is not important
for the user.) „Vac“ can also result from a disconnected
grid or a disconnected AC cable. The Sunny Boy assumes
that the public grid is down and disconnects from the grid
in order to avoid islanding.
Check the grid voltage and the grid cable connection in
the Sunny Boy enclosure. If the grid voltage is out of range
due to your local grid conditions contact the utility compa-
ny and ask, if it is possible to modify the utility conditions.
If the grid voltage is within the tolerable range and you still
observe the failure message „Vac-Bfr“ or „Vac-Srr“ contact
SMA.
Disturbance
VpvMax DC input voltage above the tolerable maximum value Warning
Watchdog Watchdog for operation control triggered. Contact SMA
for assistance. Error
Error Code Description Error Type
